Measuring Insert for Thermocouple - TC10-A
Brand: WIKA Alexander Wiegand SE & Co. KGThe measuring inserts per DIN 43735 for resistance thermometers described here are designed for installation in a protective fitting.
Operation without thermowell is only recommended in certain applications. The measuring insert is made of a bendable mineral-insulated sheathed cable.
The thermocouple is located at the tip of the measuring insert. The measuring inserts are delivered with pressure springs to ensure that the measuring inserts are pressed down to the thermowell bottom.
Features- Application ranges from 0 ... 1,200 °C (32 ... 2,192 °F).
- Made of mineral-insulated sheathed measuring cable.
- Functional safety (SIL) with model T32 temperature transmitter.
- Spring-loaded design.
- Explosion-protected versions.
Specifications
Sensor Range
- -40° to 1,200° C (-40° to 2,192° F)
Certifications & Approvals
- NAMUR NE 024
- Uzstandard
- UkrSEPRO
- BelGIM
- MTSCHS
- KazInMetr
- GOST
- PESO
- KOSHA
- Ex Ukraine
- CCC
- INMETRO
- EAC
- IECEx
- ATEX
- CE
- SIL
Sensor Type
- Thermocouple Types K, J, E, N, T
Output
- 4-20 mA, HART Protocol
Shaft Material
- Ni Alloy: Alloy 600
Environmental Protection
- IP00
- Replacement measuring insert for servicing
- For all industrial and laboratory applications
