7101A Plug & Play Accelerometer
Brand: American Sensor Technologies IncThe Model 7101A is a miniature, high performance IEPE accelerometer available in ±50 to ±1000g dynamic ranges.
The accelerometer is designed for high frequency vibration and shock measurements and offers a wide bandwidth to >10kHz utilizing stable piezo-ceramic crystals in annular shear mode. The model 7101A features a hermetically sealed titanium housing and the popular through hole mount configuration. The standard operating temperature range extends from -55° to 125°C.
Features- ±50 to ±1,000g Dynamic Range
- Welded Construction, Titanium
- Hermetically Sealed
- Annular Shear Mode
- Stable Temperature Response
- Miniature, Through-Hole Mount
- Temperature Compensated
Specifications
Accuracy
- ± 1.0 % of Full Scale Output Non-Linearity
Applications
- General-purpose Usage
- High Frequency Applications
- Laboratory Testing
- Modal Applications
- Vibration & Shock Monitoring
Approvals & Certifications
- CE
- RoHS
Constant Acceleration
- ± 50 to ± 1,000 G
Consumption
- 2-10 mA
Electrical Connectors
- M3 Coaxial Cable Connector
Excitation Voltage
- 18-30 Vdc
Frequency
- 0.5 to 10,000 Hz
Input Power
- 6-14 Vdc - Bias
NACE & NIST
- NIST
Operating Temperature
- -55° to 125° C (-67° to 257° F)
Output
- ± 5 V - Full Scale Output
Output Load
- < 100 ohms
Output Noise
- 0.001 to 0.0004 G RMS - Residual (Broadband 1 Hz to 10 kHz)
Sensitivity
- 5-100 mV/g
Sensor, Probe Material
- Ceramic - Shear Mode
Shock
- 5,000 G
Storage Temperature
- -55° to 125° C (-67° to 257° F)
Temperature Range
- -40° to 120° C (-40° to 248° F)
Torque
- 5 In/Lbs (0.6 Nm) - Mounting
Turn-On Time
- 0.8 to 1.2 seconds
