3800 Series Pressure Transmitter
Brand: Gems Sensors, Inc
The 3800 Pressure Transmitter is a compact loop-powered (4-20 mA) transmitter, with a low power 1-5 Vdc option also available. Its rugged construction makes cost of ownership low and it carries a three-year warranty.
The 3800 Pressure Transmitter is suitable for hazardous locations and hostile environments.
It meets applications where dependable, continuous monitoring is preferred. Zero and span are field adjusted via Gems calibration kit with USB communication cable.
Features- FM and ATEX Approvals for hazardous locations
- 0 to 10,000 psi (0 to 689 bar)
- Field adjustable - 5:1 turndown
- Compact, 316 Stainless Steel, hermetically sealed enclosure
- 17-4 stainless steel sensor, No o-ring
- Dual seal approval
- Flush mount option available
Specifications
Brand
Accuracy
- ± 0.25 % of URL - BFSL
Ambient Temperature Range
- -40° to 80° C (-40° to 176° F)
Approvals & Certifications
- ATEX: II 2 G Ex d IIC T5 IP66
- CE
- FM (C,US): Class I, II, III, Div. 1, & Div. 2, Group A, B, C, D, E, F, G, T5, NEMA 4X
Burst Pressure
- 10 x FSPR for psi: 0 to 2,500 (kPa: 0 to 17,240, bar: 0 to 172.4)
- 20 x FSPR for psi: 0 to 1,000 (kPa: 0 to 6,895, bar: 0 to 68.95)
- 4 x FSPR for psi: 0 to 10,000 (kPa: 0 to 68,950, bar: 0 to 689.5)
- 40 x FSPR for psi: 0 to 250 (kPa: 0 to 1,724, bar: 0 to 17.24)
- 8 x FSPR for psi: 0 to 5,000 (kPa: 0 to 34,470, bar: 0 to 344.7)
Circuit Protection
- EMI/RFI Protected
- Reverse Polarity
Compensated Temperature
- -40° to 80° C (-40° to 176° F)
Conduit Connection
- 1/2" NPT Male
Electrical Connectors
- 18 AWG Shielded Cable
Electrical Contacts
- Normally Open Solid-State Relay
Enclosure, Body Material
- 316 Stainless Steel
Environmental Protection
- Explosion-proof
- Flameproof
- Non-Incendive
Hysteresis
- ± 0.25 % of URL - BFSL
Linearity
- ± 0.25 % of URL - BFSL
Loop Resistance
- 800 ohms at 24 Vdc
Mounting
- Pipe
Name Plate, Tag Material
- Stainless Steel
NPT Connection
- 1/2" NPT Male
- 1/4" NPT Female
Output
- 1-5 Vdc (27 mW ± 5 mW @ 9 Vdc)
- 4-20 mA
Overpressure & Static Pressure Limits
- Overpressure: 2 x FSPR for psi: 0 to 10,000 (kPa: 0 to 68,950, bar: 0 to 689.5)
- Overpressure: 3 x FSPR for psi: 0 to 100 (kPa: 0 to 689.5, bar: 0 to 6.89)
Pressure Range
- bar: 0 to 690
- kPa: 0 to 69,000
- psi: 0 to 10,000
Process Temperature
- -40° to 90° C (-40° to 194° F)
Repeatability
- ± 0.25 % of URL - BFSL
Response Time
- ≤ 5 ms
Stability
- Long Term Stability: ≤ ± 0.5 % of URL Per Year
Storage Temperature
- -40° to 90° C (-40° to 194° F)
Supply Voltage
- 8-30 Vdc
Turndown
- 5:1 (Standard) (2:1 for 100 psi)
Wetted Materials
- AISI 630 Stainless Steel, 17-4 PH
