P Series Plug Valve
Brand: Hy-Lok USA, Inc
Features
- Pressure rating up to 3,000 psig (206 bar) at 70° F (21° C)
- Temperature rating from -10° to 400° F (-23° to 204° C) with PTFE coated Viton Seal
- Small and compact design
- Easy maintenance and cleaning
- Sizes available up to 1/2″ tube and pipe
- Body materials available in 316 stainless steel and brass
- 100% factory tested
Specifications
Brand
Body / Ball / Stem / End Connector Material
- 316 Stainless Steel
- Brass
Handle Material
- Black Nylon Standard
Pin/Reatining Ring Material
- Stainless Steel
Plug Material
- TP 316/A479
- Brass
- With PTFE Coated
O-ring
- FKM Standard
Orifice Size
- 4.4 mm
- 7.2 mm
Pressure Rating
- Maximum 3,000 psig (206 bar) @ 70° F (21° C)
Temperature Rating
- -10° to 400° F (-23° to 204° C)
