Ball Bearing Elements - LEW Series
Brand: Franke GmbHFranke bearing elements type LEW are suitable for medium rotational speeds and accuracies.
They convince by smooth running even under tilt moment loads, high rigidity and compact installation space.
The crosswise arranged rollers can support high loads from all directions. Bearing elements of model LEW are insensitive to shock and vibration.
They offer the greatest possible flexibility in terms of preload, running characteristics and diameter ranges.
FeaturesBearing Type
- 4 race rings with ground raceways
- Plastic cage with rollers
Characteristics
- Maximum possible integration capacity
- High stiffness
- Greatest possible flexibility of preload, runability and diameter ranges
Diameter Range
- Infinitely variable from 400 to 1200 mm
Specifications
Brand
Material
- Race Rings: 67SiCr5
- Rollers: 100Cr6
- Cage: PA12
Temperature in Use
- -30° C Bis +80° C, Briefly Up to +100° C
Circumferential Speed
- Maximum 4 m/s
Lubrication
- Shell Gadus S3 V220
Lubrication Schedule
- See Technical Information
Tolerances
- See Technical Information
