AstonWood® Steel Shingles
Brand: Tamko Building Products LLCRustic warmth. Distinctive colors.
MetalWorks AstonWood steel shingles replicate the warmth and appeal of cedar shingles with a galvanized steel.
Features- Painted galvanized steel
- Minimum slope: 3" in 12"
- Shingle width—overall: 39-3/4"
- Shingle height—overall: 12-5/8"
- Shingle exposure: 12"
- Shingles per box: 15 panels
- Coverage per box: 49.2 sq. ft. (approx. 1/2 square)
- Shingle material: 28 gauge 0.0162'' (0.041148 cm) thickness, including G-90 galvanization and paint coatings. Fluropon® coatings with primer, 1 mil dry film thickness. Interior finish is a wash coat with primer, 0.6 mil dry film thickness.
- Clip: 1-1/4" wide × 2-1/8" long × 0.20" deep
- Clip material: 0.015'' thick, G-90 galvanized steel
Specifications
UL Listed for Class A Fire Rating
- UL 790/ASTM E108, Class A
UL Classified for Wind Resistance
- ASTM D3161, Class F
UL Classified in Accordance with
- UL 2218 Class 4 Impact Resistance
UL Reports
- UL ER18590-01
Florida Building Code Approved
- FL3901
Canadian Construction Materials Centre Report
- CCMC 13011-R
Shingle Size
- 12-5/8” x 39-3/4”
Exposure
- 12”
Coverage per Box
- 49.2 sq.ft.
Shingles per Box
- 15
Shingle Material
- 28 gauge nominal 0.0162” (0.066802 cm) thickness, including G-90 galvanization and paint coatings
Exterior Finish
- Fluropon coatings with primer, 1 mil dry film thickness
Interior Finish
- Wash coat with primer, 0.6 mil dry film thickness
Clip Size
- 1-1/4” wide x 2-1/8” long x 1/5” deep
Clip Material
- 0.015” thick, G-90 galvanized steel
