SNB - SNC PFA Lined Ball Valve

Brand: Neotecha

PFA lined stainless steel ball valve with short face to face and well proven trunnion mounted design for use in pharmaceutical and bio-engineering industries.
Features
  • PFA lining offers highest corrosion resistance
  • The smooth external surface of the investment cast Stainless Steel body makes the valve an ideal selection for high integrity installations
  • Short face to face dimensions allow easy installation
  • Bubble tight shut-off: precision machined ball and seats guarantee an absolute leak-free valve
  • Full bore offers high Kv-value equal to the pipe
  • One piece ball/stem: protects the integrity of the PFA ball lining, no hysteresis, ideal for flow control applications
  • Anti blow-out shaft design, which can not be affected by the media, according API
  • Static electricity: any build-up of static electricity is eliminated since the ball/stem and the housing are of the same potential
  • Constant torque: the unique two-piece body construction together with the spring loaded seats guarantee a constant torque even after months of operation
  • The self adjusting packing is maintenance free and provides a leak free stem seal which is TA-Luft VDI 2440 approved
  • The C ball version is dead space free and allows easy cleaning in line
  • Direct mounting according to ISO 5211

Specifications

Brand

Approvals & Certifications

  • CRN, CUTR, PED, CE, Fugitive Emission

Body Design

  • Short Pattern

End Connection

  • Wafer

Material

  • Teflon, 316 Stainless Steel

Media

  • Aggressive Liquids & Gases

Operating Temperature

  • Less than 200° C

Pressure Class

  • PN

Seat / Seal Type

  • Ball

Valve Size Standard

  • DN

Valve Type

  • Ball Valve
