TM-1400 Mini Converter Unit
Brand: Tokyo Keiso Co, LtdTM-1400 is the converter especially used in combination with TC-1000, TC-2000, TC-3000 and EP-TC-1000/2000V series mass flow controllers.
It supplies power to flow controllers, indicates instantaneous flow rate with scale factor, and sets flow rate manually or externally with a change over switch.
Moreover, it outputs optionally the totalizing pulse of flow rate. These versatile functions allow easy configuration of flow control system for various kinds of gases.
Integration into one unit from independent function has realized space saving and simple, easy installation work.
Features- As small as DIN 72 square, light and space saving
- Necessary functions for process control and management are integrated into one unit as standard
- Instantaneous flow rate indication and output, totalizing pulse output, and flow rate setting function
- Easy operation as all parameters can be set at front panel
Specifications
Brand
Enclosure, Body Material
- Noryl Resin Containing Glass Fiber
Environmental Protection
- IP20
Input Signal
- 0-5 Vdc
- 1-5 Vdc
- 4-20 mA DC
Output
- 0-5 Vdc
- 4-20 mA DC
