7720 Series PVC Tube Flowmeter

Brand: King Instrument Company
Add Product to My Catalog

Type 1, Grade 1 PVC tube meters offer chemical resistance. The dial type display makes measuring opaque fluids  simple. A 4-20mA transmitter is optional.
Features
  • Unique, All PVC Meter, Type 1, Grade 1
  • C-276 Hastelloy® Internals
  • Available 4-20mA Output, NPT or Flange Connections
  • 120mm Detachable Direct Reading Scale
  • 0.55 – 450 GPM Water; Liquid Service Only

1 - 12 of 560 Part Numbers
772-1-4-1-0-706
772-1-4-1-0-706
  • Connection Type - FNPT Connections
  • Float Material - Hastelloy®C - 276
  • O-ring Material - EPR
  • Alarm/Transmitter - None
  • Water Flow - 33 GPH
772-1-4-1-0-708
772-1-4-1-0-708
  • Connection Type - FNPT Connections
  • Float Material - Hastelloy®C - 276
  • O-ring Material - EPR
  • Alarm/Transmitter - None
  • Water Flow - 1.1 GPM
772-1-4-1-0-710
772-1-4-1-0-710
  • Connection Type - FNPT Connections
  • Float Material - Hastelloy®C - 276
  • O-ring Material - EPR
  • Alarm/Transmitter - None
  • Water Flow - 2 GPM
772-1-4-1-0-712
772-1-4-1-0-712
  • Connection Type - FNPT Connections
  • Float Material - Hastelloy®C - 276
  • O-ring Material - EPR
  • Alarm/Transmitter - None
  • Water Flow - 4 GPM
772-1-4-1-0-714
772-1-4-1-0-714
  • Connection Type - FNPT Connections
  • Float Material - Hastelloy®C - 276
  • O-ring Material - EPR
  • Alarm/Transmitter - None
  • Water Flow - 6 GPM
772-1-4-1-0-716
772-1-4-1-0-716
  • Connection Type - FNPT Connections
  • Float Material - Hastelloy®C - 276
  • O-ring Material - EPR
  • Alarm/Transmitter - None
  • Water Flow - 5 GPM
772-1-4-1-0-718
772-1-4-1-0-718
  • Connection Type - FNPT Connections
  • Float Material - Hastelloy®C - 276
  • O-ring Material - EPR
  • Alarm/Transmitter - None
  • Water Flow - 10 GPM
772-1-4-1-0-720
772-1-4-1-0-720
  • Connection Type - FNPT Connections
  • Float Material - Hastelloy®C - 276
  • O-ring Material - EPR
  • Alarm/Transmitter - None
  • Water Flow - 16.5 GPM
772-1-4-1-0-722
772-1-4-1-0-722
  • Connection Type - FNPT Connections
  • Float Material - Hastelloy®C - 276
  • O-ring Material - EPR
  • Alarm/Transmitter - None
  • Water Flow - 25 GPM
772-1-4-1-0-724
772-1-4-1-0-724
  • Connection Type - FNPT Connections
  • Float Material - Hastelloy®C - 276
  • O-ring Material - EPR
  • Alarm/Transmitter - None
  • Water Flow - 35 GPM
772-1-4-1-0-726
772-1-4-1-0-726
  • Connection Type - FNPT Connections
  • Float Material - Hastelloy®C - 276
  • O-ring Material - EPR
  • Alarm/Transmitter - None
  • Water Flow - 60 GPM
772-1-4-1-0-728
772-1-4-1-0-728
  • Connection Type - FNPT Connections
  • Float Material - Hastelloy®C - 276
  • O-ring Material - EPR
  • Alarm/Transmitter - None
  • Water Flow - 76 GPM
1 - 12 of 560 Part Numbers

View_Details

Specifications

Brand

Metering Tube

  • Type 1, grade 1 PVC

Internal Components

  • Hastelloy® C-276

Fitting Material

  • Type 1, grade 1 PVC

Inlet/Outlet Fittings

  • NPT or flange, vertical

O-Ring

  • Viton®
  • Buna N
  • EPR
  • Kalrez®

Capacities

  • Water: 33 GPH to 450 GPM

Scale

  • 120 mm direct reading, detachable

Accuracy

  • ± 3% of full scale flow

Turndown

  • 10:1

Repeatability

  • 1%

Maximum Pressure

  • 150 psig, sizes 4 & 6
  • 125 psig, sizes 8, 9, 11, 12

Maximum Temperature

  • 130 °F

Documentation

Data Sheets

Catalog

Instructions
