Vegawell 52 Submersible Pressure Transmitter
Brand: VEGAVEGAWELL 52 is suitable for continuous level measurement of liquids.
Typical applications are measurements in water/waste water facilities, deep wells and in the shipbuilding industry.
Features- High reliability through maximum overload and vacuum resistance of the ceramic measuring cell
- High plant availability through integrated overvoltage protection
- Versatile use thanks to robust housing and cable version
Specifications
Brand
Accuracy
- 0.1%
- 0.10%
- 0.2%
Ambient Temperature Range
- -40° to 80° C (-40° to 176° F)
Applications
- Liquids
Approvals & Certifications
- ATEX
- CSA
- FM us
- EAC
- UKR Sepro / Ukraine
- INMETRO / Brazil
- BV
- CCS
- DNV
- LR
- RINA
- WHG
- GL
- IEC
- LRS
- ABS
BSP Connection
- G 1” Male
- G 1-1/2” Male
Cable Length
- 19.69 feet (6 metres)
- 40 to 59.06 feet (12.2 to 18 metres)
- 88.6 feet (27 metres)
Cable Material
- Fluorinated Ethylene Propylene (FEP)
- Polyethylene (PE)
- Polyurethane (PUR)
Electrical Connectors
- M20 x 1.5
Enclosure, Body Material
- Plastic
- Stainless Steel
Environmental Protection
- IP68
- IP66
- IP67
NPT Connection
- 3/4” NPT Male
Operating Voltages
- 8-35 Vdc
Output
- 4-20 mA / HART
- 4-20 mA
Output Format
- FOUNDATION Fieldbus
Pressure Range
- bar: 0.1 to 60
- kPa: 10 to 6,000
- psig: 14.5 to 870
Pressure Type
- Absolute
- Relative
Process Fitting Details
- Straining Clamp, Threaded Fitting Unassembled from G 1” or from 1” NPT Thread G 1-1/2”or from 1-1/2” NPT on the Housing
Process Temperature
- -20° to 80° C (-4° to 176° F)
Seal Material
- EPDM
- FFKM
- FKM
Sensor, Probe Diameter
- 0.8” (22 mm)
- 1.25” (32 mm)
Sensor, Probe Material
- 316L Stainless Steel
- Duplex (1.4462)
- PVDF
- Titanium
Storage Temperature
- -40° to 80° C (-40° to 176° F)
Measurig Range
- 0 to 25 bar
- 0 to 2,500 kPa
- -14.5 to 362.6 psig
- Water/Waste Water Facilities
- Deep Wells & Shipbuilding Industry
