SR301R Threaded Remote Seal
Brand: Smar International CorpThe SR301R is a threaded connection seal. The diaphragm is welded to the flange. This model is always supplied with housing, because the process thread is located in this part.
The (optional) flush connection in the housing enables to remove deposits on the diaphragm without disconnecting the seal.
The parts are bolted together and sealed with a gasket. This model is supplied with bolts and nuts in Stainless Steel 316.
Features- Remote Seal, Threaded
- Pressure measurements with indirect diaphragm contact
- Applications for processes with corrosion, viscosity, suspended solids, extreme temperatures and others
- Threaded or Tri-Clamp process connection
- Diaphragm welded to the flange
- Always comes with housing
- Pressure Limit: 2,500 psi
- Capillary Length: 0.5 to 10 m
- Diaphragm Material: 316 Stainless Steel & Hastelloy® C-276
- Fill Fluid:
- Silicone Oil - DC 200
- Silicone Oil - DC 704
- Syltherm 800
- Process connection: 1/2" NPT, 3/4" NPT, and 1" NPT
- Lower Housing: 316L Stainless Steel
- Gasket Material: Teflon (PTFE) & Grafoil (Flexible Grafoil)
1 - 12 of 1,961 Part Numbers
SR301R-311-HD-IG
- Process Connection - 1/2" NPT
- Capillary Length - 500 mm
- Diaphragm - Hastelloy C-276
- Fill Fluid - DC 704 - Silicone Oil
- Enclosure Material - 316L Stainless Steel
- Gasket Material - Grafoil (Flexible Grafoil)
- Housing Connection - Without Housing Connection
SR301R-311-HD-IG/G0
- Process Connection - 1/2" NPT
- Capillary Length - 500 mm
- Diaphragm - Hastelloy C-276
- Fill Fluid - DC 704 - Silicone Oil
- Enclosure Material - 316L Stainless Steel
- Gasket Material - Grafoil (Flexible Grafoil)
- Housing Connection - Flush Connection 1/4" NPT (If Supplied with Housing)
SR301R-311-HD-IG/G1
- Process Connection - 1/2" NPT
- Capillary Length - 500 mm
- Diaphragm - Hastelloy C-276
- Fill Fluid - DC 704 - Silicone Oil
- Enclosure Material - 316L Stainless Steel
- Gasket Material - Grafoil (Flexible Grafoil)
- Housing Connection - Two Flush Connections 1/4" NPT at 180°
SR301R-311-HD-IG0
- Process Connection - 1/2" NPT
- Capillary Length - 500 mm
- Diaphragm - Hastelloy C-276
- Fill Fluid - DC 704 - Silicone Oil
- Enclosure Material - 316L Stainless Steel
- Gasket Material - Grafoil (Flexible Grafoil)
- Flush Connection - without Flush Connection
- Housing Connection - Without Housing Connection
SR301R-311-HD-IG0/G0
- Process Connection - 1/2" NPT
- Capillary Length - 500 mm
- Diaphragm - Hastelloy C-276
- Fill Fluid - DC 704 - Silicone Oil
- Enclosure Material - 316L Stainless Steel
- Gasket Material - Grafoil (Flexible Grafoil)
- Flush Connection - without Flush Connection
- Housing Connection - Flush Connection 1/4" NPT (If Supplied with Housing)
SR301R-311-HD-IG0/G1
- Process Connection - 1/2" NPT
- Capillary Length - 500 mm
- Diaphragm - Hastelloy C-276
- Fill Fluid - DC 704 - Silicone Oil
- Enclosure Material - 316L Stainless Steel
- Gasket Material - Grafoil (Flexible Grafoil)
- Flush Connection - without Flush Connection
- Housing Connection - Two Flush Connections 1/4" NPT at 180°
SR301R-311-HD-IT
- Process Connection - 1/2" NPT
- Capillary Length - 500 mm
- Diaphragm - Hastelloy C-276
- Fill Fluid - DC 704 - Silicone Oil
- Enclosure Material - 316L Stainless Steel
- Gasket Material - Teflon (PTFE)
- Housing Connection - Without Housing Connection
SR301R-311-HD-IT/G0
- Process Connection - 1/2" NPT
- Capillary Length - 500 mm
- Diaphragm - Hastelloy C-276
- Fill Fluid - DC 704 - Silicone Oil
- Enclosure Material - 316L Stainless Steel
- Gasket Material - Teflon (PTFE)
- Housing Connection - Flush Connection 1/4" NPT (If Supplied with Housing)
SR301R-311-HD-IT/G1
- Process Connection - 1/2" NPT
- Capillary Length - 500 mm
- Diaphragm - Hastelloy C-276
- Fill Fluid - DC 704 - Silicone Oil
- Enclosure Material - 316L Stainless Steel
- Gasket Material - Teflon (PTFE)
- Housing Connection - Two Flush Connections 1/4" NPT at 180°
SR301R-311-HD-IT0
- Process Connection - 1/2" NPT
- Capillary Length - 500 mm
- Diaphragm - Hastelloy C-276
- Fill Fluid - DC 704 - Silicone Oil
- Enclosure Material - 316L Stainless Steel
- Gasket Material - Teflon (PTFE)
- Flush Connection - without Flush Connection
- Housing Connection - Without Housing Connection
SR301R-311-HD-IT0/G0
- Process Connection - 1/2" NPT
- Capillary Length - 500 mm
- Diaphragm - Hastelloy C-276
- Fill Fluid - DC 704 - Silicone Oil
- Enclosure Material - 316L Stainless Steel
- Gasket Material - Teflon (PTFE)
- Flush Connection - without Flush Connection
- Housing Connection - Flush Connection 1/4" NPT (If Supplied with Housing)
SR301R-311-HD-IT0/G1
- Process Connection - 1/2" NPT
- Capillary Length - 500 mm
- Diaphragm - Hastelloy C-276
- Fill Fluid - DC 704 - Silicone Oil
- Enclosure Material - 316L Stainless Steel
- Gasket Material - Teflon (PTFE)
- Flush Connection - without Flush Connection
- Housing Connection - Two Flush Connections 1/4" NPT at 180°
1 - 12 of 1,961 Part Numbers
Specifications
Brand
Approvals & Certifications
- 3A Sanitary
Capillary Length
- 1,000 mm
- 10,000 mm
- 2,000 mm
- 3,000 mm
- 4,000 mm
- 5,000 mm
- 500 mm
- 6,000 mm
Communication
- HART
Diaphragm Material
- 316 Stainless Steel
- Hastelloy C-276
Enclosure, Body Material
- 316 Stainless Steel
Fill Material
- DC 200 - Silicone Oil
- DC 704 - Silicone Oil
- Syltherm 800
Gasket Material
- Grafoil (Flexible Grafoil)
- Teflon (PTFE)
NPT Connection
- 1” NPT
- 1/2” NPT
- 3/4” NPT
Proof Pressure
- psi: 2,500 (kPa: 17,200, bar: 172)
