Model ML20-D Welding Saddle Meter
Brand: McCrometer, IncMcCrometer Model ML20-D Welding Saddle Meter are manufactured to the highest standards.
Materials used on all meters and flow ranges for the low velocity meter meet or exceed AWWA standard C704-02.
The weld-on design permits use in a wide range of applications with up to 150 psi working pressure.
It is necessary, upon ordering, to furnish the I.D. dimension of the pipe the meter is to be mounted on for calibration purposes.
The O.D. dimension or wall thickness must also be furnished for proper fit of the saddle to the pipe.
Specifications
Brand
Approvals & Certifications
- AWWA
Bearing Material
- Propeller Bearing: Ceramic
Enclosure, Body Material
- Meter Head: Cast Iron
- Meter Head: Steel
Environmental Protection
- IP66
- NEMA 4X
Materials of Construction
- Gearbox: Cast Bronze
- Maget: Ceramic
- Meter Head Bolt: Plated Steel
- Propeller Spindle, Separator, Meter Head Bolt: Stainless Steel
- Propeller: Thermoplastic
Pressure Rating
- psi: 150 (kPa: 1,000, bar: 10)
Size
- Meter & Nominal Pipe Size: 4" to 72"
