Water Digital Temperature Gauge
Brand: Xi'an UTOP Measurement Instrument Co, LtdTemperature gauge is designed with whole electronic structure. With Pt100 resistor, The temperature gauge can measure and display the medium temperature precisely. The installation of temperature gauge is very easy and simple.
UTY6 water digital temperature gauge is made with entire electronic structure, and uses battery as power supply. It is easy for field installation.
UTY6 water digital temperature gauge adopts high precise thermal resistor Pt100 as sensing element, and its LCD indicator displays the actual temperature reading directly. To save battery life, it has automatic turn-off function in 1~15 min if there is no operation.
Features- LCD display, without apparent value error
- Peak value recording function, record the max. temperature value during measuring process
- Temperature percentage dynamic demonstration (progress strip demonstration)
- 1~15 min automatic turn-off function
- Micro power loss function, can work above 2 years in the electricity saving pattern
Specifications
Measurement Medium
- Gas or Liquid Compatible to Stainless Steel
Temperature Ranges
- -200° to +500° C
Temperature Sensor
- PT100
Accuracy
- 0.5 % Full Scale
LCD Display
- 4-digit
Battery Power Supply
- 9 Vdc
Ambient Temperature Range
- -30° to +80° C
Process Connection
- G1/2” or Others
Material of Housing
- ABS Plastic
Material of Wetted Parts
- 1Cr18Ni9Ti
Insert Stem Diameter
- 8 mm (Standard)
OEM Service
- Yes
- Widely Used for the Measurement and Demonstration of Fluid Medium's Temperature in such Industries as:
- Water and Electricity
- Chemical
- Machinery
