Features
  • Capacity: 1 ~ 100 ton
  • Alloy steel material, surface nickel treatment suitable for different bad & dangerous conditions.
  • Shear web compression type, easy installation
  • Application for hopper scales and vehicle scales

Specifications

Capacity

  • 1 t - 100 t

Output

  • 2 ± 0.008 mV/V

Combined Error

  • 0.03 % Full Scale (Option: OIML C3)

Non-Linearity

  • ± 0.03 % Full Scale

Hysteresis

  • ± 0.03 % Full Scale

Repeatability

  • ± 0.03 % Full Scale

Creep

  • ± 0.03 % Full Scale/30 min

Zero Unbalance

  • 1 % Full Scale

Excitation Voltage

  • 9 Vdc ~ 12 Vdc

Operating Temperature Range

  • -20° ~ +55° C

Compensated Temperature Range

  • -10° ~ +40° C

Temperature Coefficient of Zero

  • 0.05 % Full Scale/10° C

Temperature Coefficient of Span

  • 0.03 % Full Scale/10° C

Input Resistance

  • 700 ± 10 Ω

Output Resistance

  • 700 ± 10 Ω

Insulation Resistance

  • ≥ 5000 MΩ @ 50 Vdc

Safe Load

  • 150 % Full Scale

Ultimate Overload

  • 200 % Full Scale

Protection

  • IP66

Electrical Resistance

  • 4-core Shielded Cable, Diameter: 5.7 mm, Length: 3 m
