SX42 High Temperature Conductivity Sensor
Brand: Yokogawa Electric Corporation
These high temperature conductivity sensors have a stainless steel body and a ceramic insulation, especially designed to withstand high temperatures (up to 250°C) and pressures (up to 40 bar).
A special treatment of the electrodes ensures optimal resistance against polarization.
The flanged model has an integral connection box, the threaded models are provided with a Amphenol connector to fit the Yokogawa WU40 cable or Variopin connector to fit with Yokogawa WU10/WE10-cable.
Features- High temperature and pressure ratings
- Built-in temperature resistor: Pt1000
- Fast temperature response
- Plug and cable form a water tight connection to IP67
- Model with flange has an integral connection box
- Threaded models have standardized connections 1” NPT or R1
- Selection of two cell constant 0.10 cm-1 or 0.01 cm-1
- Sensor with 8 pin Variopin with ID chip for SENCOM SA11-C1 use
- ATEX/IECEx certified
- Optimal resistance against polarisation
Specifications
Applications
- High Pressure Applications
- High Temperature Applications
Approvals & Certifications
- Material Certificate 3.1 According to EN 10024
- Quality Inspection Certificate
BSP Connection
- 1” BSPT Male to ISO 7-1
Connection Material
- Aluminum Terminal Box - for Flanged Models
- PBT Reinforced with Glass - for Threaded Models
Connection Style
- Flange
- Screw Terminals
Electrical Connectors
- Terminal Strip - Internal - Flanged Models
Enclosure, Body Material
- 316 Stainless Steel
Environmental Protection
- IP65
Flange Size - 2” (DN 50)
- 2” (DN 50) - 600# (ANSI B16.5)
- 2” (DN 50) - PN 64 (DIN 2527 Form E)
NPT Connection
- 1” NPT Male
Pressure Range
- psi: 0 to 363 (kPa: 0 to 2,500, bar: 0 to 25) - for Threaded Models
- psi: 0 to 600 (kPa: 0 to 4,137, bar: 0 to 40) - for Flanged Models
Principle of Operation
- 2-Electrode System
Sensor, Probe Type
- Pt1000 to IEC 751 - Temperature Sensor
Temperature Range
- 0° to 200° C (32° to 392° F) - for Threaded Models
- 0° to 250° C (32° to 482° F) - for Flanged Models
Wetted Materials
- 316 Stainless Steel - Electrodes, Lance
- Ceramic (Aluminum Oxide) - Insulation
