RubberGard™ EPDM Platinum™ System
Brand: Holcim ElevateDesigned with 90-mil of uninterrupted thickness, the RubberGard™ EPDM Platinum™ System is, quite simply, our best roof.
With RubberGard EPDM Platinum Systems you’ll enjoy the benefit of the Elevate Red Shield™ Platinum Warranty that includes 30-year coverage.
Features- Watertight Seams
- Installation Options
- Performance and Longevity
- 90-mil thickness and 10’ wide, no-fold panels, available in both black and white.
- Mechanical, fully adhered or ballasted options.
- Resistance to UV radiation, ozone and weathering, as well as offers low temperature properties.
- More flexible than thermoplastic membranes, allowing year-round application.
Specifications
Brand
Thickness (D412)
- 2.286 mm +0.343 mm/-0.229 mm (.090″ +0.0135″/-0.009″)
Tensile Strength (D412, Die C)
- 9.0 MPa (1305 psi) Min.
Dynamic Puncture Resistance at 5J (D5635)
- Pass
Static Puncture Resistance at 20 kg (44.1 lbf) D5602)
- Pass
Elongation, Ultimate % (D412, Die C)
- 300 % Min.
Tensile Set (D412, Method A, Die C, 50% Elongation)
- 10 % Max.
Tear Resistance D624, Die C)
- 26.27 kN/m (150 lbf/in) Min.
Brittleness Point (D2137)
- -45º C (-49º F) Max.
Ozone Resistance, No Cracks (D1149)
- Pass
Tensile Strength After Heat Aging
- 8.3 MPa (1205 psi) Min.
Elongation, Ultimate After Heat Aging
- 200 % Min.
Tear Resistance After Heat Aging
- 21.9 kN/m 125 lbf/in Min.
Linear Dimensional Change After Heat Aging
- ± 1 %
Water Absorption by Mass
- +8%/-2%
Visual Inspection After Xenon-Arc Weather Resistance
- Pass
PRFSE, Minimum % After Xenon-Arc Weather Resistance
- 30 % Min.
Elongation, Ultimate, Minimum % After Xenon-Arc Weather Resistance
- 200 % Min.
- Commercial
- Government
- Hospitals and Universities
