AST Plug & Play Accelerometer, 7114A

7114A Plug & Play Accelerometer

Brand: American Sensor Technologies Inc
Add Product to My Catalog

The Model 7114A is a high performance IEPE accelerometer available in ±5 to ±50 g dynamic ranges.

The stud mounted accelerometer features a welded hermetic construction with a side mount connector. The model 7114A incorporates stable piezo-ceramic crystals in annular shear mode which provide a wide bandwidth. The standard operating temperature range extends from -55° to 125°C. For a miniature stud mount version please review model 7104A, available in ±50 to ±500 g dynamic ranges.
Features
  • ±5 to ±50 g Dynamic Range
  • High Sensitivity, 1,000 mV/g
  • Welded Construction
  • Hermetically Sealed
  • Annular Shear Mode
  • Stable Temperature Response

1 - 3 of 3 Part Numbers
7114A-0005
7114A-0005
  • Range - 5 G
7114A-0010
7114A-0010
  • Range - 10 G
7114A-0050
7114A-0050
  • Range - 50 G
1 - 3 of 3 Part Numbers

View_Details

Specifications

Brand

Approvals & Certifications

  • CE
  • RoHS

Cable Length

  • 10 feet (3 metres) Standard

Current

  • 2-10 mA - Excitation Current

Electrical Connectors

  • 10-32 Coaxial Cable Connector

Enclosure, Body Material

  • Stainless Steel

Environmental Protection

  • IP67

Frequency

  • 0.5 to 9,000 Hz
  • 26,000 to 30,000 Hz - Natural Frequency

Humidity

  • Hermetically Sealed

Load Impedance

  • Output Impeance: < 100 ohms

Mounting

  • #10-32 to #10-32 Mounting Stud

NACE & NIST

  • NIST Traceable Amplitude Calibration from 20 Hz to ± 1 dB Frequency Response Limit

Non-Linearity

  • ± 1 % of Full Scale Output

Operating Temperature

  • -55° to 125° C (-67° to 257° F)

Operating Voltages

  • 18-30 Vdc - Compliance Voltage

Output

  • ± 5 V - Full Scale Output

Output Noise

  • 0.0001 to 0.0004 G RMS - Residual (Broadband 1 Hz to 10 kHz)

Response Time

  • Discharge Time Constant: 0.8 to 1.2 seconds

Sensitivity

  • < 5 % - Transverse Sensitivity
  • 100-1,000 mV/g

Sensor, Probe Material

  • Ceramic (Shear Mode)

Shock

  • 5,000 G

Storage Temperature

  • -55° to 125° C (-67° to 257° F)

Supply Voltage

  • 6-13 Vdc - Bias Voltage
  • 8-12 Vdc - Bias Voltage

Torque

  • 18 In/Lbs (2.0 Nm)

  • General-purpose Usage
  • High Frequency Applications
  • Laboratory Testing
  • Modal Applications
  • Vibration & Shock Monitoring
