Model AK Pneumatic Actuators
Brand: KTMCompact and light-weight actuator, equipped with a guide rod for smooth operation and extended durability.
Features- Double acting and single acting type are of the same shape and dimension.
- Double rack and pinion gear construction produces a smooth uniform stroke throughout the whole range.
- Guide rod eliminates side loading of the piston for smooth actuation and greater durability.
- Double rack design allows for a larger cylinder bore and shorter piston stroke, resulting in a more compact unit and high torque.
- ISO 5211 mounting pattern to provide the greatest flexibility for valve adaptation.
- Air supply port (piping seat) and stem top conform to NAMUR standards for simple and direct mounting of accessories.
- Interchangeable spring return sets according to each operating pressure/torqe.
