Model 341 High Accuracy Pressure Transducer

Brand: GP:50 New York Ltd

Features
  • Output Signal: 4-20 mA
  • Supply Voltage: 8 to 32 Vdc
  • Pressure Range: 0 to 30" WC (0 to 15,000 psi, 0 to 1034, 0 to 103,421 kPa
  • Burst Pressure: 5 times FSO or 22,500 psi maximum
  • Proof Pressure: 2 times FSO or 22,500 psi maximum
  • Electrical Connections: PTIH-10-6P
  • Process Connection: 1/4" Male NPT
  • Temperature Range:
    • Operating: -40° to 85°C (-40° to 185°F)
    • Compensated: 0° to 82°C (32° to 180°F)
    • Storage: -40° to 121°C (-40° to 250°F)
    • Effect on Zero/Span: ±0.5% Full Scale Output at 100°F
  • Static Accuracy: ±0.10% Full Scale Output
  • Materials of Construction:
    • Housing: 300 Series Stainless Steel
    • Wetted Parts: 316 Stainless Steel

Specifications

Accuracy

  • ± 0.05 % of FSO
  • ± 0.10 % of FSO

Burst Pressure

  • 5 x FSO or 22,500 psi (1,551 bar, 155,132 kPa), whichever is less

Circuit Protection

  • Reverse Polarity

Compensated Temperature

  • 0° to 82° C (32° to 180° F)

Electrical Connectors

  • Bendix PTIH-10-6P

Enclosure, Body Material

  • 300 Stainless Steel

Load Impedance

  • 1,150 ohms Max.

NPT Connection

  • 1/4" NPT Male

Operating Temperature

  • -40° to 85° C (-40° to 185° F)

Output

  • 4-20 mA

Pressure Range

  • bar: 0 to 1,034
  • inH₂O: 0 to 30
  • kPa: 0 to 103,421
  • psi: 0 to 15,000

Pressure Type

  • Absolute
  • Gauge
  • Sealed Gauge
  • Vacuum

Proof Pressure

  • 2 x FSO or 22,500 psi (1,551 bar, 155,132 kPa) whichever is less

Response Time

  • 1 ms

Span & Zero Effect

  • ± 0.5 % of FSO at 38° C (100° F)

Storage Temperature

  • -40° to 121° C (-40° to 250° F)

Supply Voltage

  • 8-32 Vdc

Wetted Materials

  • 316 Stainless Steel
  • 630 Stainless Steel
