SWS-147 BCD/RS-485 Meter
Brand: SIMEX sp. z o.o.The SWS-94 is a simple digital panel indicator intended for displaying any numerical values and characters defined by user - in SLAVE mode only, sent from the master device over the RS-485 serial interface link.
The displayed value may be collected from other device - in MASTER mode.
The display brightness can be adjusted in 8 steps.
Modbus RTU protocol is used to communication with device. Baud rate is user defined in 1200 ÷ 115200 baud range.
The meter can be configured with the local keyboard or free S-Config software via the RS-485 communication port.
Features- Indicator with a Large, 20 or 13 mm high, LED Display
- RS-485 / Modbus RTU
- MASTER / SLAVE
- Transmission Speed Adjustable: 1200 ÷ 115200 bit/sek.
- Display Brightness Adjustable in 8 Steps
- Password Protected
- Free Configuration Software S-Config
Specifications
Brand
Input Type
- No Input
Output Type
- No Output
Power Supply
- 16...35 Vac, 19...50 Vdc
- 85..260 Vac/dc
- 11,4...15 Vac/dc
Display
- LED, 4 x 38 mm, red
- LED, 4 x 38 mm, green
Communication Interface
- RS-485 / Modbus RTU
Transmission Parameters
- 1200...115200 bit/s
- 8N1 / 8N2
Operating Temperature
- 0...+50° C
- -20…+50° C
Protection Class
- IP 20: Case and Connection Clips
- Optional Integrated Frame for Panel Cut-out Sealing
- IP 65: Front
Case Material
- NORYL-GFN2S E1
Mounting
- Panel
Case Dimensions
- 144 x 72 x 100 mm
