Smith Meter® Model K12-S1 Meter - Spare Parts
Brand: TechnipFMC
The Smith Meter Model K12 Meter is a 12", double-case, straight-through-type, rotary vane, positive displacement flow meter and is part of the CT series of large PD meters.
The CT series PD Meters incorporate design features including lightened blades, full-width wear strips, and tungsten carbide roller pins to provide extended service in harsh crude applications.
The crude transportation series is suitable for both crude oil and refined product applications such as blending, batching and leak detection as well as traditional custody transfer applications.
Features- High-viscosity meter clearances extend operation at maximum flow rate from 200 to 2,000 millipascal-second (mPa•s)
- High-temperature clearances extend operating temperatures from 115 to 200 degrees Fahrenheit (°F) (46 to 93 degrees Celsius (°C))
- All iron trim option for operating temperatures above 200°F (93°C)
- Liquefied petroleum gas (LPG) trim option for low-lubricity liquids, such as LPG
- Compliant with NACE standard MR-01-75
- ASME Section VIII vessel construction is available for model K12-S3
1 - 12 of 201 Part Numbers
001111-001
001292-401
001627-400
002238-401
002801-400
003440-001
003540-001
003551-001
003552-001
003553-001
003556-001
003557-001
1 - 12 of 201 Part Numbers
Specifications
Brand
Maximum Flow Rate
- Continuous Rating with Standard Trim: 7200 BPH / 1140 m³/h
- Continuous Rating with All Iron or LPG Trim: 5400 BPH / 855 m³/h
Repeatability
- ± 0.02 %
Viscosity
- Standard: 200 mPa.s³ (1,000 SSU) maximum
- Optional: 2 Pa.s (10,000 SSU) maximum – specify “High Viscosity Meter Clearances.”
- Over 2 Pa.s: Specify “High Viscosity Meter Clearances” and derate maximum flow rate in direct proportion to viscosity over 2 Pa.s (e.g., at 4 Pa.s, derate maximum flow rate to 50% of normal continuous rating - 3600 BPH)
Temperature - Standard Meter Clearances with
- Buna-N/PTFE: -20°F to 115°F (-29°C to 46°C)
- FKM: 10°F to 115°F (-12°C to 46°C)
- Low Temperature FKM: -50°F to 115°F (-46°C to 46°C)
Temperature - High Temperature Meter Clearances with
- Buna-N/PTFE: -20°F to 200°F (-29°C to 93°C)
- FKM: 10°F to 200°F (-12°C to 93°C)
- Low Temperature FKM: -50°F to 200°F (-46°C to 93°C)
Temperature - All Iron Trim with
- Buna-N: -20°F to 225°F (-29°C to 108°C)
- FKM: 10°F to 400°F (-12°C to 205°C)
- Low Temperature FKM: -50°F to 400°F (-46°C to 205°C)
Meter Gearing
- One barrel or 1 hectolitres per revolution of meter calibrator output shaft
- Fifty gallons―Special
