CSS 120 Static Holder
Brand: M4 KnickThe CSS 120 static holder enables quick and easy installation of pH/ORP, conductivity, or dissolved oxygen sensors in process applications.
The CSS 120 can be used in new applications as well as for direct retrofit of existing sensors.
When used in combination with our sensors and cables, the CSS 120 will reduce both maintenance and replacement costs associated with potted sensor technology.
Features- Replace sensors without having to dispose of the holder and cable
- Quick disconnect at the sensor head eliminates the need to remove wires from a junction box or transmitter for maintenance
- Lower cost of ownership
- Reduces sensor replacement cost
- Reduces maintenance cost
Specifications
Brand
Mounting Options
- 3/4”, 1″, and 1-1/2” MNPT
- Flange from 1″ ANSI
Sensor Length
- 120 mm
Sensor Connection
- Pg 13.5
Materials of Construction
- 316L Stainless Steel, PP, PVDF, other materials available upon Request
Operating Pressure Range
- 316L Stainless Steel: 0…150 psi (0…10 bar)
- PP: 0 … 60 psi (0 … 4 bar), 14 … 50° F (-10° C …10° C) 60 psi (4.13 bar), 50 … 140° F (10 … 60° C) Ambient, 140 … 176° F (60 … 80° C)
- PVDF: 0 … 90 psi (0 … 6.21 bar), 14 … 32° F (-10 … 0° C) 90 psi (6.21 bar), 32 …194° F (0 … 90° C) Ambient , 194 …284° F (90 …140° C)
Operating Temperature Range
- 316L Stainless Steel: 14 … 284° F (-10° … 140° C)
- PP: 14 …176° F (-10 … 80° C)
- PVDF: 14 … 248° F (-10 … 120° C)
Sealing Materials
- EPDM, Viton, Kalrez
Protective Cage
- Standard
Insertion Lengths
- 1.375″ (3/4″ NPT version only), 2.25″, 4.09″
- Custom lengths on Request
