Automizer Right Hand
Brand: Labrie GroupThe Automizer Right-Hand™, equipped with its strong, and precise arm is the most sought-after ASL in the market today.
Features- Best in class
- Unmatched versatility
- One piece AR steel
- Alternative energy: EV or CNG powered
Specifications
Brand
Body Floor
- 0.157” AR450 175,000 psi
Body Sides (Lower)
- 10 ga A1011 80,000 psi
Body Roof
- 12 ga A1011 80,000 psi
Tailgate
- 12 ga A1011 80,000 psi
Hopper Size (yd³)
- 6.5
Hopper Floor
- 1/4” AR450 175,000 psi
Hopper Sides (Lower)
- 1/4” AR450 175,000 psi
Pump Make & Model
- Dual Vane
Pump Capacity
- BODY: 20.4 gpm @ 700 rpm
- ARM: 16.3 gpm @ 700 rpm
Maximum Operating Pressure
- 3,000 psi (2,000 psi on single axle chassis)
Oil Reservoir
- 94 gal
Arm Lift Capacity
- 1,000 lbs
Arm Reach
- 144”
Swing Out
- 36”
Arm Controls
- Proportional joystick, electric over hydraulic
Compaction Ratio (lbs/yd³)
- 850 (650 on single axle chassis)
Packer Panel Face Plate
- 1/4” 100QT 100,000 psi
Packer Width
- 64-1/2”
Packer Height
- 24”
Packer Stroke
- 52”
- Automated
- Residential
- Recycling
