Polytron 8310 IR Flammable Gas & Vapor Detector
Brand: Drägerwerk AG & Co. KGThe Dräger Polytron 8310 IR is an advanced explosion proof transmitter for the detection of combustible gases in the lower explosion limit (LEL).
It uses an infrared Dräger Sensor IR that can be configured for methane, propane, or ethylene.
Besides a 3-Wire 4 to 20 mA Analog output with relays, it also offers Modbus and Fieldbus protocols making it compatible with most control systems.
Specifications
Brand
Ambient Temperature Range
- -40° to 65° C (-40° to 149° F)
Approvals & Certifications
- ATEX
- CE
- CSA Class I, Div. 1, Groups B, C, D, Class II, Div. 1, Groups E, F, G, Class I, Zone 1, Group IIC, Temp. Code T6/T4
- DNV GL
- IECEx
- MED
- UL Class I, Div. 1, Groups B, C, D, Class II, Div. 1, Groups E, F, G, Class I, Zone 1, Group IIC, Temp. Code T6/T4
Communication
- FOUNDATION Fieldbus
- HART
- Modbus RTU
- PROFIBUS PA
Consumption
- w/o Relay, Non-Remote 145 mA at 24 V
- With Relay, Remote 185 mA at 24 V
Enclosure, Body Material
- Transmitter, Sensor: 316L Stainless Steel
- Transmitter: Aluminum
Environmental Protection
- IP65
- IP66
- IP67
- NEMA 4X
- NEMA 7
Humidity
- 0 to 100 % Relative Humidity, Non-Condensing
Power Supply
- 10-30 Vdc, 3-Wire
