KTM/KTMR Thermistor & RTD Sensor
Brand: Kele
The Kele KTM/KTMR Series Thermistor and RTD encapsulated sensors provide remote temperature sensing for building automation systems and mechanical equipment room instrumentation.
The active sensing element is a highly stable thermistor material or platinum RTD. The sensor is encapsulated with a low mass, high conductivity compound for good heat transfer characteristics.
It is enclosed in a tough, miniature cylinder, 0.17" (0.43 cm) in diameter, which is small enough to be installed in most HVac thermostat enclosures.
Features- Wide selection of thermistor and RTD curves
- Adaptable miniature sensor
- High Heat Dissipation Constant
- Easy to mount with clips
- Pre-aged, highly stable thermistor material
Specifications
Brand
Accuracy
- ± 0.28° C (± 0.50° F) - Thermistor
- ± 0.33° C (± 0.60° F) - RTD
Applications
- HVac Equipment
Approvals & Certifications
- CE
Approvals & Certifications
- Compliance/Conformance
Dissipation
- 2.7 mW/°C (Power Needed to Raise the Temperature 1° C (1.8° F)) - Heat Dissipation
Electrical - Free Leads
- 18” (45 cm) Free Leads
Electrical Connectors
- 24 AWG, 25 feet (7.6 metres)
Materials of Construction
- Platinum - RTD
Mounting
- Clip
- Wall Mounted
NACE & NIST
- NIST
Operating Temperature - Sensor
- 2° to 60° C (35° to 140° F) - KTM
- -34° to 110° C (-30° to 230° F) - KTMR
Resistance
- 2.252 to 100 kiloohms - Thermistor
RTD Type
- Pt375, 1,000 ohms - Typical 91
- Pt385, 100 ohms - Typical 81, 1,000 ohms - Typical 85
Sensor, Probe Connection
- 3-Wire
Sensor, Probe Type
- RTD
- Thermistor
Stability
- 0.13° C (0.24° F) over 5-Years - Thermistor
Temperature Coefficient
- Negative Temperature Coefficient - Thermistor
- Positive Temperature Coefficient - RTD
Temperature Range
- -40° to 105° C (-40° to 221° F) - Thermistor/RTD
