Emerson KTM Ball Valve, EB548/EB545 Series

Series EB548/EB545 Floating Ball Valve

Brand: KTM
Add Product to My Catalog

A two piece fire safe and anti-static reduced bore, screwed/weld end ball valve for the chemical and petroleum industries.
Features
  • Designed to ASME B16.34.
  • Two piece locked body design eliminates body bolting.
  • Fire Safe tested and certified to API 607 by Lloyd’s Register Asia.
  • Screwed connection to ASME B1.20.1 (NPT) and BS 21 (BSPT).
  • Socket welded dimensions to ASME B16.34 / ASME B16.11.
  • Extended welded ends are available as an option.
  • Socket weld valve face-to-face dimensions allows inline welding.
  • Forged carbon steel or stainless steel body.
  • Integral mounting flange for ease of actuation.
  • Integral padlocking wrench kit option.
  • Precision stainless steel ball and stem is standard in all trims.
  • Vented ball equalizes body cavity pressure in open position and prevents seat damage.

Specifications

Brand

Approvals & Certifications

  • CE, Fire Safe, NACE, PED, CRN

Body Design

  • Side Entry

End Connection

  • Butt Weld, Socket Weld, Weld End

Material

  • Carbon Steel, 316 Stainless Steel, 316L Stainless Steel, Duplex, Inconel, Stainless Steel, Super Duplex

Media

  • Aggressive Liquids & Gases, CNG, Liquids, Natural Gas, LPG

Pressure Class

  • ASME

Process Connection Type

  • NPT, Threaded, SWE, BWE

Seat / Seal Type

  • Soft Seal, Ball

Shutoff Class

  • API 598, Zero Leakage

Standards

  • API 608, ASME B16.34

Valve Size

  • NPS 3/4 / DN 20, NPS 2 / DN 50, NPS 1 / DN 25, NPS 1/2 / DN 15, NPS 1-1/2 / DN 40

Valve Size Standard

  • DN, NPS

Valve Type

  • Ball Valve, Floating Ball Valve

  • Fire & Gas Systems
  • Gas Gathering & Compression
  • Fuel Gas
  • FPSO
  • Separation
  • Corrosive
  • City Gate / Distribution Station
  • Bulk Storage
  • Burner Management Systems
  • City Gates & District Stations

Documentation

Data Sheets

Brochure
