McCrometer Weld-On Saddle Meter, Model MW600

Model MW600 Weld-On Saddle Meter

Brand: McCrometer, Inc
Add Product to My Catalog

Model MW600 Weld-On Saddle Meter is machined to the same radius as the tube on which it is to be installed to provide accurate alignment.

The Model MW600 is manufactured to comply with applicable provisions of American Water Works Association Standard No. C704-02 for propeller-type flowmeters.

As with all McCrometer propeller flowmeters, standard features include a magnetically coupled drive, instantaneous flowrate indicator and straight reading, six-digit totalizer.

Specifications

Brand

Accuracy

  • ± 1 % over Reduced Range
  • ± 2 % of Reading

Bearing Material

  • Ball Bearing: 440C Stainless Steel

Enclosure, Body Material

  • Bearing Housing: 304 Stainless Steel
  • Bearing Housing: 316 Stainless Steel
  • Bearing Housing: Brass
  • Bearing Housing: Stainless Steel
  • Die Cast Aluminum Case

Materials of Construction

  • Impeller: High-impact Plastic
  • Magnet: Alnico

Pressure Rating

  • psi: 150 (kPa: 1,000, bar: 10)

Repeatability

  • 0.25 % or Better

Shaft Material

  • 316 Stainless Steel

Size

  • Meter SIze: 4” to 48”

Temperature Range

  • Maximum 160° F

Documentation

Data Sheets
