Wilcoxon Sensing Technologies Industrial Piezoelectric Accelerometer, Model 793-10

Model 793-10 Industrial Piezoelectric Accelerometer

Brand: Wilcoxon Sensing Technologies
Add Product to My Catalog

Top exit, 2-pin MIL-C-5015 connector, case isolated, 10 mV/g premium accelerometer.
Features
  • Rugged, general-purpose
  • Corrosion resistant
  • Priced economically for single and OEM quantities
  • Hermetically sealed
  • Standardized sensitivity
  • Ground isolated
  • ESD protection
  • Reverse wiring protection
  • Intrinsically safe certified option

Specifications

Brand

Applications

  • Engine Monitoring
  • Machinery Monitoring
  • Predictive Maintenance
  • Ship Board Machinery
  • Shock & Vibration
  • Shock Pulse Measurements

Approvals & Certifications

  • ATEX Ex

Electrical Connectors

  • Cable (J9T2A / J10)
  • Mating Connector: R6 Typical
  • Output Connector: 2-Pin, MIL-C-5015 Style

Enclosure, Body Material

  • Stainless Steel

Frequency

  • Frequency Response (± 10 %): 2 to 7,000 Hz
  • Frequency Response (± 3 dB): 1 to 15,000 Hz
  • Frequency Response (± 5 %): 3 to 5,000 Hz
  • Resonance Frequency, Mounted, Nominal: 25 kHz

Humidity

  • 100 % Relative Humidity

Mounting

  • 1/4-28 Tapped Hole

Noise

  • Electrical Noise, Equivalent G, Nominal (Broadband: 2.5 Hz to 25 kHz): 4,500 µg
  • Electrical Noise, Equivalent G, Nominal (Spectral: 1,000 Hz): 20 µg/√Hz
  • Electrical Noise, Equivalent G, Nominal (Spectral: 10 Hz): 50 µg/√Hz
  • Electrical Noise, Equivalent G, Nominal (Spectral: 100): 40 µg/√Hz

Non-Linearity

  • Amplitude Non-Linearity: 1 %

Output Impedence

  • Maximum 100 Ω

Power Requirement

  • 18-30 Vdc
  • Current Regulating Diode: 2-10 mA

Range

  • Acceleration Range: 500 G Peak

Sensitivity

  • Base Strain Sensitivity: 0.001 G/μstrain
  • Electromagnetic Sensitivity, Equivalent G: 15 µg/Gauss
  • Sensitivity, ± 10 %, 25° C (77° F): 10 mV/g
  • Transverse Sensitivity: Max. 5 % of axial

Shock

  • Shock Limit: 5,000 G Peak

Temperature Range

  • -50° to 120° C (-58° to 248° F)

Vibration

  • Vibration Limit: 500 G Peak

Voltage

  • Bias Output Voltage, Nominal: 12 Vdc

Documentation

Data Sheets
