PCE-28.SMART / PCE-28.SMART/EXD Smart Pressure Transmitter

Brand: Aplisens S.A.

Features
  • 4…20 mA output signal + HART protocol
  • Intrinsic safety certificate (ATEX, IECEx)
  • Explosion proof certificate (ATEX, IECEx)
  • Accuracy 0.1%
  • Marine certificate – DNV, BV

Specifications

Certifications & Approvals

  • DNV
  • BV
  • IECEx
  • NACE
  • ATEX

Accuracy

  • 0.1%

Thermal Error

  • < ± 0.08 % FSO / 10° C
  • Maximum ± 0.25 % (FSO) in the Whole Compensation Range

Measuring Range

  • -0.5 to 1,380 bar
  • -100 to 100 mbar
  • 0 to 300 bar abs

Minimum Set Range

  • 0.07 to 13.8 bar (7 to 138 kPa)
  • 5 to 100 mbar (0.5 to 10 kPa)
  • 0.25 to 100 mbar abs (25 to 10 kPa abs)

Thermal Compensation Range

  • -25° to 80° C

Power Supply

  • PCE-28.SMART/EXD: 7.5-30 Vdc
  • PCE-28.SMART: 7.5-55 Vdc (Ex 7.5-30 Vdc)

Output Signal

  • 4-20 mA, Two Wire Transmission

Wetted Parts and Diaphragm

  • 316L Stainless Steel, Hastelloy C-276

Case Material

  • 304 Stainless Steel
  • 316 Stainless Steel

Operating Temperature

  • PCE-28.SMART/EXD: -40° to 80° C
  • PCE-28.SMART: -40° to 85° C

Medium Temperature Range

  • -40° to 120° C

Environmental Protection

  • IP68
  • IP66
  • IP65
  • IP67

Communication

  • 4-20 mA + HART
