140 Series Proportional Pressure Control Valve
Brand: IMI NorgrenProportional current to pressure closed loop converter, intrinsically safe with ATEX, FM and CSA approvals.
Fail safe operation so that in the event of a control signal failure output pressure falls to zero. Ideally suited to process control applications in hazardous environments where certified products are required.
Features- Advanced Electronic Control
- Explosion Proof / Intrinsically Safe / Type nA nL
- Complete Electronics Modularity for Ease of Maintenance
- Jack Socket for On-Site Monitoring
- Fail-Safe (unit pressure falls to zero on signal failure)
- Field Replaceable Filter
- Weatherproof (IP66 or Type 4X)
- High Performance and Accuracy
- Fast Response and Minimal Temperature Effect
- Large Flow Capacity
Specifications
Brand
Air Consumption
- < 2.5 NL/minute at 50 % Signal
Ambient Temperature Range
- -40° to 85° C (-40° to 185° F)
Approvals & Certifications
- ATEX
- CE
- CENELEC
- CSA
- FM
- SIRA
BSP Connection
- G 1/4” Female
Calibration
- Unit is Factory Calibrated within 1 % of Span
Circuit Protection
- 100 mA Max. Overload Current
Conduit Connection
- 1/2” NPT
- M20
Diaphragm Material
- Nitrile
Enclosure Finish
- Epoxy Powder-Coated
Enclosure, Body Material
- Aluminum & Zinc Die Casting
Environmental Protection
- IP66
- NEMA 4X / IP66
Exhaust Port
- 1/8” NPT
Flow Capacity
- Up to 300 Nl/min
Hysteresis
- Mean < 0.1 % of Span
Independent Linearity
- Mean < 0.1 % of Span
Input Signal
- 4-20 mA
Media
- Oil Free, Dry Air & Filtered to 50 µm
NPT Connection
- 1/4” NPT Female
Pressure Range
- bar: 0.2 to 2
- kPa: 20 to 200
- psi: 3 to 30
Response Time
- < 1 second (From 0 to 90 % of Output Pressure Into A 0.5L Load)
Sensitivity
- (Leak)< 0.875 % of Span for up to 3 scfm Downstream Leakage
- (Supply) < 0.1 % of Span for Full Supply Pressure Range
- (Temperature) < 0.06 % of Span/°C between -40 to 85° C (-40° to 185° F)
Span & Zero Adjustments
- Independently Adjustable Tight Shut Off Point up to 4.5 mA
Supply Pressure
- bar: 1.2 to 10
- kPa: 120 to 1,000
- psig: 18 to 150
Vibration Effect
- < 3 % for Vibration Amplitude
