Polytron 8700 IR Flammable Gas & Vapor Detector

Brand: Drägerwerk AG & Co. KG

The Dräger Polytron 8700 IR is an advanced explosion proof transmitter for the detection of combustible gases in the lower explosion limit (LEL).

It uses a high performance infrared Dräger PIR 7000 sensor, which will quickly detect most common hydrocarbon gases.

Besides a 3-Wire 4 to 20 mA Analog output with relays, it also offers Modbus and Fieldbus making it compatible with most control systems.

Specifications

Ambient Temperature Range

  • -40° to 77° C (-40° to 170° F)

Approvals & Certifications

  • ATEX
  • CE
  • CSA Class I, Div. 1, Groups B, C, D, Class I, Zone 1, Group IIC, Temp. Code T6/T4
  • DNV GL
  • IECEx
  • MED
  • UL Class I, Div. 1, Groups B, C, D, Class II, Div. 1, Groups E, F, G, Class I, Zone 1, Group IIC, Temp. Code T6/T4

Approvals & Certifications

  • SIL 2 Certified by TUEV Sued, Certificate No. Z10 1207 53474 013

Communication

  • FOUNDATION Fieldbus
  • HART
  • Modbus RTU
  • PROFIBUS PA

Consumption

  • w/o Relay, Non-Remote 330 mA at 24 V
  • With Relay, Remote 350 mA at 24 V

Enclosure, Body Material

  • Transmitter, Sensor: 316L Stainless Steel
  • Transmitter: Aluminum

Environmental Protection

  • IP65
  • IP66
  • IP67
  • NEMA 4X
  • NEMA 7

Humidity

  • 0 to 100 % Relative Humidity, Non-Condensing

Measuring Range

  • 0 to 100 % by Volume
  • 0 to 100 % Lower Explosive Limit (LEL)

Power Supply

  • 10-30 Vdc, 3-Wire
