MZ Series High Range DP Pressure Difference Switch
Brand: Orion InstrumentsMZ Series pressure switches have been designed for applications that require cost effective outdoor mounting in aggressive environments.
The tough polycarbonate cover, fitted on a stainless steel base, retained by SS screws offers excellent resistance to corrosion, and also allows a view of the integral scale and working of the pressure switch.
The reliable microswitch offers narrow dead band, switching values, which have excellent repeatability.
By using appropriate capsules and wetted parts, MZ series pressure switches can be used for thousands of applications.
Features- Robust Externally visible scale, with tough polycarbonate cover
- Enclosure protection: IP66 standard
- Reliable accurate micro switching values
- Customized arrangements for switching values
- Easy, safe wiring connections
- Locking and sealing arrangements to avoid tampering of setpoints on field
- Accuracy: ±1% Full ScaleR
Specifications
Brand
Accuracy
- ± 1 % of Full Scale Range
Ambient Temperature Range
- Operating Ambient Temperature: -20° to 60° C (-4° to 140° F)
Applications
- Boilers & Compressors
- Burner & Furnaces Control
- Chemical Industry
- Fire Protection Systems
- Glass & Metal Industry
- Hydraulic, Stream & Gas Turbines Equipment
- Machine Tools
- Power Generation Equipment
- Steel Industry
- Sugar & Paper Mills
- Surgical Gas, Breweries, Milk Industries
- Tyre Industry
- Water Treatment
Approvals & Certifications
- CE
BSP Connection
- 1/4” BSP Female
Cable Entry
- M20 x 1.5 Female
Diaphragm Material
- 316L Stainless Steel
- Monel
- Neoprene
- Teflon
Differential Pressure
- psi: 1.74 to 11.60 (kPa: 12 to 80, bar: 0.12 to 0.80) - Max.
Electrical Rating
- Microswitch: 5 A at 250 Vac
Enclosure, Body Material
- Tough Polycarbonate
Environmental Protection
- IP66
Operating Pressure
- Maximum
Process Connection Material
- 316 Stainless Steel
- Monel
Process Temperature
- Rubber Diaphragm, Max.
Repeatability
- ± 1 % of Full Scale
Set Point - Decreasing
- bar: 0.1 to 25
- kPa: 10 to 2,500
- psi: 1.45 to 362.3
Set Point - Increasing
- bar: 0.1 to 25
- kPa: 10 to 2,500
- psi: 1.45 to 362.6
Switch Quantity
- SPDT: 2 Switches
Switch Type
- Micro Switch
- SPDT
System Pressure
- bar: 0 to 70
- kPa: 0 to 7,000
- psi: 0 to 1,015.26
