4332M3 Plug & Play Accelerometer
Brand: American Sensor Technologies IncThe Model 4332M3 is 4-20 mA output MEMS triaxial accelerometer offering both static and dynamic response.
The accelerometer is packaged in a corrosion resistant stainless steel housing and is offered in ±2 to ±20 g range. The model 4332M3 features an integral cable and is certified to IP68 protection up to 40 m depth with an operating temperature range of -40° to 85° C.
Features- Stainless Steel Housing
- Corrosion Resistant
- Three Independent Circuits
- ±2 to ±20 g Dynamic Range
- DC Response
- Temperature Compensation
1 - 12 of 1,596 Part Numbers
4332M3-002-010
- Range - ± 2 G
- Cable Length - 1 Custom Length: Inches
4332M3-002-020
- Range - ± 2 G
- Cable Length - 2 Custom Length: Inches
4332M3-002-030
- Range - ± 2 G
- Cable Length - 3 Custom Length: Inches
4332M3-002-040
- Range - ± 2 G
- Cable Length - 4 Custom Length: Inches
4332M3-002-050
- Range - ± 2 G
- Cable Length - 5 Custom Length: Inches
4332M3-002-060
- Range - ± 2 G
- Cable Length - 6 Custom Length: Inches
4332M3-002-070
- Range - ± 2 G
- Cable Length - 7 Custom Length: Inches
4332M3-002-080
- Range - ± 2 G
- Cable Length - 8 Custom Length: Inches
4332M3-002-090
- Range - ± 2 G
- Cable Length - 9 Custom Length: Inches
4332M3-002-100
- Range - ± 2 G
- Cable Length - 10 Custom Length: Inches
4332M3-002-1000
- Range - ± 2 G
- Cable Length - 100 Custom Length: Inches
4332M3-002-1010
- Range - ± 2 G
- Cable Length - 101 Custom Length: Inches
1 - 12 of 1,596 Part Numbers
Specifications
Accuracy
- ± 0.5 % of Full Scale Output - Non-Linearity
Applications
- Bridge Monitoring
- Low Frequency
- Structural Monitoring
- Submersible Measurements
- Transportation Measurements
Approvals & Certifications
- CE
- RoHS
Cable Material
- PVC
Compensated Temperature
- 0° to 65° C (32° to 149° F)
Constant Acceleration
- ± 2 to ± 20 G
Consumption
- < 15 mA - Quiescent Current
Enclosure, Body Material
- 316 Stainless Steel
Environmental Protection
- IP68
Excitation Voltage
- 7-24 Vdc
Frequency
- 0 to 300 Hz
Hysteresis
- ± 0.5 % of Full Scale Output
Insulation Resistance
- > 100 megaohms at 100 Vdc
Mounting
- M3 Screws
NACE & NIST
- NIST
Operating Temperature
- -40° to 85° C (-40° to 185° F)
Output
- 12 ± 0.25 mA - Zero Acceleration
- 4-20 mA - Full Scale Span
Output Noise
- 25 to 200 µg RMS
Resistance
- < 100 ohms - Output Impedance
Sensitivity
- ± 0.04 %/°C
- 0.4 to 4 mA/g
Shock
- 5000 G - Shock Limit
Storage Temperature
- -40° to 85° C (-40° to 185° F)
Thermal Drift
- ± 0.04 % of Full Scale Output/°C - Thermal Zero Shift
Torque
- 6 In/Lbs (0.7 Nm) - Mounting
Turn-On Time
- < 100 milliseconds
