INSTALINK-CMM Continuity Monitoring Module

Brand: Emphatec
Add Product to My Catalog

The INSTALINK-CMM module was designed with process automation in mind. In applications with critical control loops the CMM module provides a continuous indication that the loop integrity is intact regardless of the status of the field device or the PLC/DCS digital output.

The user configures the module for use with either digital inputs or digital outputs. Configuration is via a jumper on the module. A small leakage current is introduced into the loop and is monitored to verify continuity in the loop.
Features
  •  Monitors continuity in 24 Vdc digital input and output loops

  •  Provides a digital output if the continuity is interrupted

  •  Includes a 100 mA 5 x 20 mm fuse eliminating the need for additional fuse terminals

    • Specifications

    Brand

    Approvals & Certifications

    • UL (C,US) E256770

    Current

    • Fuse: 5 x 20 mm, 100 mA
    • Leakage Current: 0.5 mA

    Electrical Connectors

    • 16 to 14 AWG

    Indication

    • Green Status LED

    Mounting

    • 32 mm & 35 mm DIN Rails

    Operating Temperature

    • -20° to 70° C (-4° to 158° F)

    Output

    • 24 Vdc at 50 mA

    Resistance

    • Resistor: 100 kiloohms, Max.

    Supply Voltage

    • 24 Vdc at 10 mA Nominal

    Termination

    • 26 to 12 AWG

    Documentation

    Data Sheets
