Emerson KTM Ball Valve, EB598 Series

Series EB598 Ball Valves

Brand: KTM
Add Product to My Catalog

3-piece, full bore, floating ball valve, suitable for a wide range of arduous applications for the oil and gas, petrochemical and process industries, where fire-safe design is mandatory.
Features
  • Full bore valves provide an unrestricted flow path for higher flow rates.
  • 100% of valves are pressure tested.
  • Certificate of Compliance to EN 10204 / ISO 10474 Type 3.1 (DIN 50 049) are supplied as standard.
  • Winged body design allows the mounting of actuators without having to remove the body bolts and maintain seal integrity.
  • Three piece body allows swing out center section for fast and easy maintenance.
  • Integral padlocking as standard on manual valves.
  • Blow-out proof stem.
  • Vented ball equalizes body cavity pressure in open position and prevents seat damage.
  • Vented seats equalizes pressure over upstream seat when used in high differential pressure applications and thereby reduces operating torque.
  • Fully machined carbon PTFE seats are standard ensuring bubble-tight shut-off.
  • A choice of seating material options are available.
  • Carbon steel or stainless steel body and end connections available.

Specifications

Brand

Approvals & Certifications

  • Fire Safe, PED, Regional, CE, CRN

Body Design

  • Side Entry

End Connection

  • Threaded, Socket Weld, Butt Weld

Material

  • 316L Stainless Steel, 316 Stainless Steel, Carbon Steel

Pressure Class

  • ASME

Process Connection Type

  • BWE, NPT, SWE, BSP, Threaded

Seat / Seal Type

  • Soft Seal, Ball

Shutoff Class

  • API 598, Zero Leakage

Standards

  • API 608, ASME B16.34

Style

  • Emergency Shutoff Valves

Valve Size

  • NPS 1 / DN 25, NPS 1/2 / DN 15, NPS 1-1/2 / DN 40, NPS 1-1/4 / DN 32, NPS 3/4 / DN 20, NPS 1/4 / DN 8, NPS 3/8 / DN 10

Valve Size Standard

  • DN, NPS

Valve Type

  • Floating Ball Valve, Ball Valve

  • Facilities & Process Utilities
  • FPSO
  • Custody Transfer Systems
  • City Gates & District Stations
  • Gas Gathering & Compression
  • Separation
  • Storage & Distribution
  • Bulk Storage
  • Boilers

Documentation

Data Sheets

Brochure
