PA Coupler SK-3 Profibus DP/PA Segment Coupler
Brand: VEGAThe segment coupler is used for coupling and power supply of Profibus PA networks.
The coupler combines two different networks for data transmission and delivers the current for the Profibus DP segment. Data are transmitted from the Profibus DP master via the segment coupler to the PA field device.
In conjunction with Profibus DP, the segment coupler supports a baud rate of up to 12 Mbit/s.
Features- Simple setup because no own GSD, DTM or EDD file or Profibus address must be used
- Flexible through support of baud rates of up to 12 Mbit/s on the Profibus DP side
- Economical solution through power supply of up to two different PA segments
Specifications
Brand
Ambient Temperature Range
- -40° to 60° C (-40° to 140° F)
Approvals & Certifications
- ATEX
Communication
- Baud Rate: 12 Mbps - PROFIBUS DP
- PROFIBUS DP
- PROFIBUS PA
Environmental Protection
- IP20
Input Signal
- FOUNDATION Fieldbus
Mounting
- Carrier Rail 35 x 7.5 According to EN 50022
Output
- FOUNDATION Fieldbus
Supply Voltage
- 25 V with 360 mA - PROFIBUS PA
