Digital Pt100 Temperature Switch Controller

Brand: Xi'an UTOP Measurement Instrument Co, Ltd

UTS3 intelligent digital pt100 temperature controller is a temperature measurement & control product with intelligent digital display, it is combined the functions of temperature measurement, display, output and control.

This product has Two-channel control point relay output 220 V / 3 A.

UTS3 digital pt100 temperature controller is designed with whole electronic structure by adopting Pt100 temperature sensor as sensing element, the signal is converted by high precise conversion, and then processed by the microprocessor.

UTS3 digital pt100 temperature controller is presently widely used for fluid temperature measurement, display and control in the water and electricity, petroleum, chemical industries.
Features
  • Dial 100 mm;
  • 4-digit LED display, without apparent value error
  • Two-channel control point relay output 220V/3A
  • 4 20 mA standard analog signal output (optional)
  • Two-channel control point can be set on the spot

Specifications

Measurement Medium

  • Gas or Liquid Compatible with Stainless Steel

Temperature Ranges

  • -200° to +500° C

Relay Output

  • 220 V / 3 A

Output Signal

  • 4 ~ 20 mA (Option)

Controlling Accuracy

  • 0.5 % Full Scale (Standard)

Display Range

  • -1999 ~ 9999

Display Accuracy

  • 0.1 % Full Scale

Long-Term Stability

  • < 0.2 % Full Scale/year

Supply Voltage

  • 24 Vdc (Standard), 220 Vac

Ambient Temperature Range

  • -30° to +80° C

Storage Temperature Range

  • -40° to 100° C

Display

  • 0.56” LED

Service Life of Switch

  • > 1 million times

Response Time

  • < 30 milliseconds

Process Connection

  • G1/2” or Others

Material of Housing

  • Stainless Steel

Material of Wetted Parts

  • 1Cr18Ni9Ti

Relative Humidity

  • 0 ~ 90 %

Protection

  • IP65
