DOE - OEM Oval Gear Flow Meter
Brand: KOBOLD Instruments, IncThe DOE oval gear, or oval wheel, positive-displacement flow meters are the OEM's preferred choice for measuring viscous, non-abrasive, clean liquids such as lubricating and hydraulic oils, petroleum, grease, pastes, diesel fuels, ink, chemicals, solvents and resins.
This compact flow meter uses 2 precision-machined oval gears which allow for a specific volume of liquid to pass through the meter with each rotation.
These gears enable the DOE to precisely measure liquid flow over a very wide viscosity range.
As this is designed to be an OEM product, minimum order quantities will apply.
Features- Pulse Frequency Signal Output
- Hall Sensor or Hall/Reed Switch
- Stainless Steel Body w/PEEK or PPS Rotors
- Media Viscosities from 2 to 1000 cP
Specifications
Brand
Measuring Range
- 0.14-9.5 GPH to 16-634 GPH
Process Connection/Type
- 1/8” to 1/2” NPT Thread
- G1/8 to G1/2
Maximum Pressure
- 928 psig
Maximum Temperature
- Up to 176° F
Housing Material
- Stainless Steel
Rotor Material
- PEEK
- PPS
Media Category
- Liquid
