Livestock U-Frames with Gates

With no overhead frame, you have one less thing to hit with your tractor (or your head). If you need to move something that is wider than the gate opening and you can lift it higher than the U-frame then you’re free to carry on without impediment. Additionally, because there are no overhead frames, you will now have a clear, unobstructed view of your corrals.

Your typical overhead frames with built-in gate are available up to 12’ wide. U-frames however will allow for a 16’ wide gate in an 18’ wide U-frame. The extra four feet may be what you need to provide access for your farm tractors and heavy equipment.

You can save money by not investing in a lot of extra steel above your head. If you are considering a 10’ or 12’ high overhead frame with built-in gate, then the U-frame offers you a more economical option.

The heavy-duty U-frame is built for strength and durability. The strength of the U-frame is secured in the 4.5” OD, 0.237 wall ground tube foundation. You can be certain that the ground tube will not deflect when the biggest guy you know decides to hang on the end of your 14’ gate.

The strength found in the foundation continues up into an unyielding 13” wide steel trussed hinge post. In addition to adding strength the offset hinge post also provides a safe zone for the handler between the open gate and the outside of the alley.

The U-frame is designed to connect with any Hi-Hog panel and is an outstanding option for livestock corrals, rodeo facilities, and round pens. No need to worry about putting posts in the ground or having frames overhead.

When the U-frame is installed correctly the bottom 4.5″ OD rail will be buried in the ground so that the top of the ground tube is even with the top of the ground. When the U-frame is buried the connectors on the end posts are at the standard height for connecting with Hi-Hog’s panels.

There are times however when one might not be able to bury the bottom ground rail. If this is true for your application you don’t need to worry because the connectors for the U-frame have been extended to allow panels and spreaders to still be attached on the end of the U-frame.

Hi-Hog offers the U-frame in both 5’ and 6’ heights. If you own the 5’ high U-frame and you need a 6’ high U-frame you can add the optional 12” extension kit to convert your 5’ high U-Frame to a 6’ high U-frame.
