HLST200 Indicating Level Transmitter

Brand: Hayward Industries, Inc

The HLST200 Series Indicating Level Transmitter offers advanced level and temperature reading indication and transmission.

The multicolor, configurable LCD graphical display provides easy viewing of process variables.

Built-in relays, open collectors, analog outputs and serial output allow a wide range of communications and control options.
Features
  • Indicate liquid level in inches, feet or meters
  • Temperature indication and transmission included
  • Highly accurate, +/- 0.2%
  • Rugged industrial design
  • Dual channel: 4-20 mA and PT100/PT1000 RTD inputs
  • Configurable LCD graphical display, changes colors to indicate alarm conditions
  • ¼ DIN size
  • NEMA 4X IP65 protection front panel
  • AC and DC power options
  • Removable terminal strips
  • Powered 4-20mA input loop
  • Dual 4-20 mA outputs
  • Dual 5A, 250 V programmable relays
  • Dual programmable open collector outputs
  • RS485 MODBUS option
  • Simple, intuitive set-up
  • Mounting hardware included
  • Combine with HLS Series Level Sensor for complete system
  • NEMA 4X/IP65 pre-wired enclosures available

Specifications

Sealing Material

  • FPM
  • EPDM

Maximum Level ft/H₂O

  • 6 ft
  • 15 ft
  • 33 ft

Cable Length

  • 20 ft
  • 30 ft
  • 50 ft
