Trimod Besta Opto Electronic Level Switch, Type OPG05

Type OPG05 Opto Electronic Level Switch

Brand: Trimod Besta
Add Product to My Catalog

The optoelectronic sensor contains an infrared LED and a light receiver. Light from the LED is directed into a prism which forms the tip of the sensor.

With no liquid present, light from the LED is refl ected within the prism to the receiver. When rising liquid immerses the prism, the light is refracted by the liquid, leaving little or no light reaching the receiver. Sensing this change, the receiver initates a switching process.
Features
  • Small and compact
  • Liquid temperature up to 175° C
  • Maximum Pressure 25 bar
  • Mounting direction: any
  • High reliability
  • Measuring accuracy ±0.5 mm
  • Electrical connection: cable connection, plug M12 or angular plug
  • Output PNP
  • Close or Open
  • Adjustable sensitivity for any application

Specifications

Brand

BSP Connection

  • 1/2” BSPP Male

Enclosure, Body Material

  • 303 Stainless Steel, 1.4305

Environmental Protection

  • IP65

Accuracy

  • ± 0.5 mm

Supply Voltage

  • 12-32 Vdc

Supply Current

  • Maximum 40 mA

Ambient Temperature

  • -30° to +80° C

Liquid Temperature

  • -40° to +170° C

Documentation

Data Sheets
