FC Series Low ΔP High Proof P62 Pressure Difference Switch

Brand: Orion Instruments

FC Pressure Switches have been designed for use in areas which are potentially explosive.

These can be used, by selecting an appropriate construction, for gas groups IIA, IIB and IIC.

They can also be used in underground mines by selecting Grey CI flameproof heads.
Features
  • Compact, rugged design
  • Enclosure protection: IP66 standard
  • Reliable, accurate micro switch arrangement can be provided
  • Easy, safe wiring connections
  • High/low pressure options available
  • Accuracy: ±1% Full Scale, ±2% Full Scale

Specifications

Accuracy

  • ± 1 % of Full Scale Range
  • ± 2 % of Full Scale Range

Applications

  • Bulk Drug & Pharma
  • Chemical Industry
  • Oil & Gas
  • Petrochemical Plants
  • Refineries

Approvals & Certifications

  • ATEX
  • CE
  • IECEx

BSP Connection

  • 1/4” BSP Female

Cable Entry

  • 1/2” NPT Female
  • 3/4” NPT Female
  • M20 x 1.5 Female

Diaphragm Material

  • Neoprene
  • Teflon

Differential Pressure

  • Inches WC: 2.007 to 14.05
  • psi: 0.073 to 0.508 (mbar: 5 to 35, kPa: 0.5 to 3.5) - Max.

Electrical Rating

  • Microswitch: 15 A at 250 Vac
  • Microswitch: 5 A at 250 Vac

Enclosure, Body Material

  • Aluminum
  • Cast Iron
  • Stainless Steel

Environmental Protection

  • Flameproof
  • IP66

Head Material

  • Aluminum
  • Grey Cast Iron
  • Stainless Steel

NPT Connection

  • 1/4” NPT Female

Operating Pressure

  • Maximum

Operating Temperature

  • Operating Ambient Temperature: 0° to 60° C (32° to 140° F)

Pressure Type

  • Differential

Process Connection Material

  • High Pressure Port: 316 Stainless Steel

Process Temperature

  • Media Temperature: for Non-Metallic Diaphragm, Max.

Repeatability

  • ± 1 % of Full Scale

Set Point - Decreasing

  • Inches WC: 2.007 to 140.52
  • kPa: 0.5 to 35
  • mbar: 5 to 350
  • psi: 0.07 to 5.07

Set Point - Increasing

  • Inches WC: 2.007 to 140.52
  • kPa: 0.5 to 35
  • mbar: 5 to 350
  • psi: 0.07 to 5.07

Switch Quantity

  • SPDT: 2 Switches

Switch Type

  • DPDT
  • SPDT

System Pressure

  • bar: 0 to 110
  • kPa: 0 to 11,000
  • psi: 0 to 1,595
