T650 High-Performance 0.8 w/m-K Thermal Grease for General-Purpose Use
Brand: ChomericsParker Chomerics T650 Thermal Grease is a general purpose grease ideal for applications on heat sinks with a thermal conductivity of 0.8 W/m-k.
T650 is a pale blue material with a 24 month shelf life and high operating temperature range (-50 • 200°C).
Parker Chomerics thermal greases offer a range of performance covering the simplest to the most demanding thermal requirements.
These materials are screened, stenciled or dispensed and require virtually no compressive force to conform under typical assembly pressures.
The excellent surface wetting results in low interfacial resistance.
Features- Silicone based materials conduct heat between a hot component and a heat sink or enclosure
- Fills interface variable tolerances in electronics assemblies and heat sink applications
- Dispensable, highly conformable materials require no cure cycle, mixing or refrigeration
- Thermally stable and require virtually no compressive force to deform under typical assembly pressures
- Supports high power applications requiring material with minimum bond line thickness and high conductivity
- Ideal for rework and field repair situations
Specifications
Brand
Package Type
- 8 ounce Container
- 1 gallon pail
Color
- Pale Blue
Specific Gravity
- 2.3
Dynamic Viscosity
- 190000 cP
Operating Temperature
- -50° to 200° C
Thermal Conductivity
- 0.8 watt/m-K
Thermal Impedance
- 0.13 @ 50° C, 0.13 @ 65° C °C-Cm²/W
Heat Capacity
- 1 J/g-K
Coefficient of Thermal Expansion
- 300 ppm/K
Volume Resistivity
- 10^14 Ω-Cm
Specifications Met
- RoHS
Outgassing Total Mass Loss
- 0.21 %
Shelf Life
- 12 Months
